NGK LB10F Suppressor
€13.98Inc. VAT
NGK LB10F Suppressor
How to identify the suppressor?
The first letter indicates the shape
- L: 90° elbow
- S: Straight
- X: 102° elbow
- V: Long 120° elbow
- Y: Short 120° elbow
- T: T-type
The second letter indicates the thread diameter
- B: Diameter 14mm
- C: Diameter 10mm
- D: Diameter 10 and 12mm
- Z: Diameter 10, 12, 14mm
The third indication, which is the number, informs about its resistance
- Empty: 0 kilowatt
- 01: 1 kilowatt
- 05: 5 kilowatt
- 10: 10 kilowatt
The penultimate letter informs about the spark plug tip
- E: Tip with olive
- F: Tip without olive
The last letter indicates the appearance of the cap
- A: Special design
- F: For 5 mm diameter high-voltage cable
- G: With gasket for engine volute
- H: Compact type
- K: Waterproof silicone seal
- L: Wound resistance
- M: Rubber sheath
- P: Special waterproof seal
- S: Shielded
- Y: With gripping lug
- Z: Special shape
8358
Data sheet
- Weight
- 0.027
- Key dimension
- 21 mm
- Thread diameter
- 14 mm
- Thread length
- 19 mm
- Spark plug type
- Resistive, equipped with a resistance that reduces high-frequency interference
- Base type
- A gasket
- Material
- Ceramic
Specific references
