Fixing pin for the blade support for Del Morino DMK 90, 100 and 110 flail mower. Original part Delmorino reference 40500005

Blade for Del Morino PUGIO 160, 200, 3P, PUGP160, PUGP200, PU3P vegetable shredder. Mounting: 3 holes (Hole Ø: 10 mm - Centre distance: 37 mm) Length: 105 mm Width: 40 mm Thickness: 6.5 mm Original part Del Morino reference BIO346D

Mounted on flail mower DMK150/3 (150 cm 3 blades) and 180/3 (180cm 3 blades) Assembly on 3-blade support (see accessory for 150/3) Mounting Ø 40 mm Length: 600 mm Width: 80 mm Thickness: 12 mm Original part Del Morino reference DMK173CD Attention blade sold individually

Mounted on DMK180/3 flail mower (180cm 3 blades) Mounting on 3-blade support Fixing Ø 40 mm Length: 750 mm Width: 90 mm Thickness: 12 mm Original part Del Morino reference DMK173DD

Counter-knife for Delmorino SCUTUM and Caravaggi BIO 90 plant shredder Mounting: 3 holes Width: 44 mm Length: 140 mm Thickness: 7 mm Bore:  8.5 mm Original part Del Morino reference BIO557D

Blade ring, spacer for Delmorino flail mower DMK 90, DMK 100 and DMK 110 External diameter: 34 mm Internal diameter: 20 mm Height: 9 mm Original part Delmorino reference DMK178D

Seal ø 71.5 per ucf 207 DELMORINO 41100048 - ORIGINAL PART

Blade for professional mowers and Delmorino ET100, PSM100 finishing mowers Mounting 2 holes: Upper hole Ø 13 mm / Lower hole Ø 9 mm Centre-to-centre distance : 85 mm Length : 432 mm <ul...

For 3-point finishing mowers: Delmorino: ET120, ET120P, PSM120, in working widths of 120, 135, 150 and 180 cm: PRM, FMRD, SRM, FM and XRM235 Agrint, Colombia 4 mounting holes; Ø 11 mm Height: 220 mm Ø support: 140 mm Ø upper shaft: 25 mm Ø lower shaft shoulder: 19 mm Side centre distance: 86 mm Diagonal centre...

For Delmorino DMK 90, 100, 110, 120, 135, 150/2 flail mowers. Used to secure the blade support fixing nut. Original part Del Morino reference 42700002

For Del Morino Grinder Flipper 80, 106 cm (2018) Flipper up to 158 cm (previous models). Original part reference Del Morino 41000021

To be fitted on Delmorino FM120, FMRD120, SRM120, PRM120 3-point finishing mowers Length: 1519 mm Width: 17 mm Thickness: 11 mm Original part Del Morino reference 42800001

To be mounted on finishing mower Delmorino ET120, PSM120, 120L, 120P, Flipper 80-106-132 cm, Centurion 106-132-158 cm, Centurion 3C 106-132-158 cm. Outer length: 1269 mm Width: 17 mm Height: 11mm Original part Del Morino reference 42800007

Nut for fixing the blade support of Del Morino flail mowers DMK 90, 100 and 110 Original part Del Morino reference 40200021

Counter blade for Delmorino Pugio vegetation shredder (Ø 5 – 6 cm, model PUGP 160, 200 PU 3P) Mounting: 2 holes Height: 40 mm Width: 95 mm Thickness: 8 to 12 mm Hole diameter: 8.5 mm Original part Del Morino BIO338D reference

Mounted on flail mower DMK120, DMK35, DMK150/2 blades Mounting on 2-blade support Mounting Ø 40 mm Length: 500 mm Width: 80 mm Thickness: 12 mm Original part Del Morino reference DMK173BD

Mounted on flail mower DMK90, DMK100, DMK110 Mounting on 2-blade support Fixing Ø 34 mm Length: 395 mm Width: 75 mm Thickness: 7 mm Original part Del Morino reference DMK543AD Attention blade sold individually and not in pairs

Blade bearing for Delmorino ET100 and PSM100 finishing mowers - ! manufactured before 2012 ! ! 25 mm mounting ! Gearbox output shaft diameter: 25 mm Blade mounting center distance: 85 mm Length: 425 mm Width: 90 mm Original part Del Morino reference ET061VD

Blade mower finishing 3 point ET 120 and PSM 120. Length: 620 mm Width: 20 mm Bore: 21 mm Original blade Del Morino reference SRM202D

Del morino washer 40300015 Dimension: diameter: 4.3 cm Thickness: 1 cm Width: 0.3 cm

Mounted on DEL MORINO Funny Super 106 and 132 cm shredders Exterior length: 1069 mm Width: 17mm Thickness: 11mm Original part Reference Delmorino 42800039

Blade spacer ring for Delmorino flail mower: DMK 120 , DMK 135, 150/2 (2 blades), 150/3 (3 blades), 180/3 (3 blades) Outer diameter: 40 mm Inner diameter: 20 mm Height: 13 mm Original part Del Morino reference DMK180D

Reference: 42000010 Compatible : PSM120 - SRM120 - PRM120 -SRM150 - PRM150 - SRM180 - PRM180 - XRM235

For Delmorino XRM, XFM 3-point finishing mowers with 235 cm cutting width Length: 3117 mm Width: 17 mm Height: 11 mm Original part Del Morino reference 42800004

Transmission belt for DEL MORINO Centurion Super 106, 132, 158 and Flipper 158, 186, 214, URC shredders Length: 1272 mm Width: 16.3 mm Thickness: 15 mm Original Part Delmorino reference 42800014

Blade bearing for Delmorino ET100 and PSM100 mowers ! Manufactured 2012 and after ! ! 30 mm mounting ! Blade shaft diameter: 30 mm Angle drive housing diameter: 30 mm Blade mounting spacing: 85 mm Length: 425 mm Width: 90 mm Original part Reference: Del Morino ET071VD

Fits on mower Del Morino PRM120, SRM120 Outside diameter: 120 mm Bore: 25 mm Height 44 mm

Washer 40300016 Size: 5.5 cm diameter 1.5 cm thickness 0.5 cm width
