Blade screw nut for Del morino flail mowers DMK 90, 100, 110, 120, 135, 150/2, 180. Original part Del morino reference 40200018

Fixing pin for the blade support for Del Morino DMK 90, 100 and 110 flail mower. Original part Delmorino reference 40500005

Seal ø 71.5 per ucf 207 DELMORINO 41100048 - ORIGINAL PART

Mounted on flail mower DMK150/3 (150 cm 3 blades) and 180/3 (180cm 3 blades) Assembly on 3-blade support (see accessory for 150/3) Mounting Ø 40 mm Length: 600 mm Width: 80 mm Thickness: 12 mm Original part Del Morino reference DMK173CD Attention blade sold individually

Mounted on DMK180/3 flail mower (180cm 3 blades) Mounting on 3-blade support Fixing Ø 40 mm Length: 750 mm Width: 90 mm Thickness: 12 mm Original part Del Morino reference DMK173DD

Blade spacer ring for Delmorino flail mower: DMK 120 , DMK 135, 150/2 (2 blades), 150/3 (3 blades), 180/3 (3 blades) Outer diameter: 40 mm Inner diameter: 20 mm Height: 13 mm Original part Del Morino reference DMK180D

Mounted on flail mower DMK90, DMK100, DMK110 Mounting on 2-blade support Fixing Ø 34 mm Length: 395 mm Width: 75 mm Thickness: 7 mm Original part Del Morino reference DMK543AD Attention blade sold individually and not in pairs

Countersunk screw for DMK flail mower 090, 100, 110, 120, 135, 150/2 (2 blades), 150/3, 180/3 (3 blades) Thread: 19 mm Length: 55 mm Original part Del Morino reference 40100037

Blade for Del Morino PUGIO 160, 200, 3P, PUGP160, PUGP200, PU3P vegetable shredder. Mounting: 3 holes (Hole Ø: 10 mm - Centre distance: 37 mm) Length: 105 mm Width: 40 mm Thickness: 6.5 mm Original part Del Morino reference BIO346D

For Delmorino DMK 90, 100, 110, 120, 135, 150/2 flail mowers. Used to secure the blade support fixing nut. Original part Del Morino reference 42700002

To be mounted on finishing mower Delmorino ET120, PSM120, 120L, 120P, Flipper 80-106-132 cm, Centurion 106-132-158 cm, Centurion 3C 106-132-158 cm. Outer length: 1269 mm Width: 17 mm Height: 11mm Original part Del Morino reference 42800007

Nut for fixing the blade support of Del Morino flail mowers DMK 90, 100 and 110 Original part Del Morino reference 40200021

To be fitted on Delmorino FM120, FMRD120, SRM120, PRM120 3-point finishing mowers Length: 1519 mm Width: 17 mm Thickness: 11 mm Original part Del Morino reference 42800001

Mounted on DEL MORINO Funny Super 106 and 132 cm shredders Exterior length: 1069 mm Width: 17mm Thickness: 11mm Original part Reference Delmorino 42800039

Counter blade for Delmorino Pugio vegetation shredder (Ø 5 – 6 cm, model PUGP 160, 200 PU 3P) Mounting: 2 holes Height: 40 mm Width: 95 mm Thickness: 8 to 12 mm Hole diameter: 8.5 mm Original part Del Morino BIO338D reference

Blade bearing for Delmorino ET100 and PSM100 finishing mowers - ! manufactured before 2012 ! ! 25 mm mounting ! Gearbox output shaft diameter: 25 mm Blade mounting center distance: 85 mm Length: 425 mm Width: 90 mm Original part Del Morino reference ET061VD

Del morino washer 40300015 Dimension: diameter: 4.3 cm Thickness: 1 cm Width: 0.3 cm

For Del Morino Grinder Flipper 80, 106 cm (2018) Flipper up to 158 cm (previous models). Original part reference Del Morino 41000021

Mounted on DEL MORINO FM150, PRM150 and SRM150 rear mower with rear or side ejection. External length: 1819 mm Internal length: 1750 mm Thickness: 11 mm Width: 17 mm Original part Delmorino reference 42800002

Counter-knife for Delmorino SCUTUM and Caravaggi BIO 90 plant shredder Mounting: 3 holes Width: 44 mm Length: 140 mm Thickness: 7 mm Bore:  8.5 mm Original part Del Morino reference BIO557D

Reference: 42000010 Compatible : PSM120 - SRM120 - PRM120 -SRM150 - PRM150 - SRM180 - PRM180 - XRM235

For Delmorino XRM, XFM 3-point finishing mowers with 235 cm cutting width Length: 3117 mm Width: 17 mm Height: 11 mm Original part Del Morino reference 42800004

Transmission belt for DEL MORINO Centurion Super 106, 132, 158 and Flipper 158, 186, 214, URC shredders Length: 1272 mm Width: 16.3 mm Thickness: 15 mm Original Part Delmorino reference 42800014

Straight harrow tooth (L = 180) for Delmorino Rotex power harrow working width: 90, 110, 130, 150 cm. Original part Reference Del Morino ERP303D

Blade bearing for Delmorino ET100 and PSM100 mowers ! Manufactured 2012 and after ! ! 30 mm mounting ! Blade shaft diameter: 30 mm Angle drive housing diameter: 30 mm Blade mounting spacing: 85 mm Length: 425 mm Width: 90 mm Original part Reference: Del Morino ET071VD

The most common blade spindle on mower decks of US-made AYP Roper, Electrolux, Bernard Loisirs, Husqvarna riding mowers.   Blade spindle 130794, 532130794 Complete blade spindle with 5-point star blade mounting For 92 cm, 96 cm and 107 cm cutting decks Adaptable 5-star blade spindle

Washer 40300016 Size: 5.5 cm diameter 1.5 cm thickness 0.5 cm width

Reference: 42000025 Angle drive for mower Delmorino PSM100 ET100
